Norwood Metal Siding
Norwood is a pre-painted steel siding from MAC Metal Architectural with the look of spaced wood planks: a beveled edge, a shadow line between boards, and fasteners that stay hidden. It's galvanized steel, non-combustible, tested to ASTM E2768 for use in California's Wildland-Urban Interface (WUI) zones, and rated Class A under ASTM E84.
It comes in two widths. The standard Norwood panel covers 5-3/8 inches and Norwood Mini covers 3.4 inches, both 12 feet long in 24 or 26 gauge. Mix the two in a repeating pattern for a custom board layout, or stick with one size for a clean, even wall. A vented panel is available in the standard size for soffits.
Each wood color comes in six plank shades mixed in every box, so the wall reads like real boards instead of a repeating print. Choose from nine colors with coordinating trims. There's nothing to stain or repaint, and MAC backs Norwood with a 40-year warranty. Data sheets, technical drawings and the installation guide are in the Downloads section below.
Sizes
| Size | Width | Length | Depth | Gauge |
|---|---|---|---|---|
| Norwood Panel | 5-3/8" | 12' | 7/16" | 24 or 26 |
| Norwood Mini Panel | 3.4" | 12' | 7/16" | 24 or 26 |
Vented Panel Available in the Norwood Standard Size
for specs and sizes of moldings/trims, see downloadable sheets below
Downloads
Norwood One Page Info Sheet - Download
Norwood Data Sheet - Download
Norwood Mini Data Sheet - Download
Molding/Trims Spec Sheet - Download
Norwood Standard Panel Technical Drawing - Download
Norwood Vented Panel Technical Drawing - Download
Norwood Mini Panel Technical Drawing - Download
Installation Guide - Download
